| Model | IPC2121SR3-PF36 | IPC2121SR3-PF60 | IPC2121SR3-PF120 |
| Camera | |||
| Sensor | 1/3″, 1.3 megapixel, progressive scan, CMOS | ||
| Lens | 3.6mm@F1.8
Angle of view(H): 76.7° |
6.0mm@F1.8
Angle of view(H): 46.9° |
12.0mm@F1.8
Angle of view(H): 24.2°
|
| Shutter | Auto/Manual, 1/6~1/8000 s
|
||
| Min. Illumination | Colour: 0.06 Lux (F1.4, 50IRE)
0 Lux with IR on
|
||
| Day/Night | IR-cut filter with auto switch (ICR)
|
||
| IR Range | Up to 30m (98 ft) IR range | ||
| S/N | >50dB | ||
| WDR | Digital | ||
| Noise Reduction | 2D/3D | ||
| Video | |||
| Max. Resolution | 1280×960 | ||
| Video Compression | H.264/MJPEG | ||
| Frame Rate | 960P (1280*960): Max. 25 fps; 720P (1280*720): Max. 30 fps; D1 (720*576): Max. 25 fps | ||
| Video Streaming | Triple | ||
| ROI | Supported | ||
| OSD | Up to 8 OSDs | ||
| Motion Detection | Up to 2 areas | ||
| Privacy Mask | Up to 4 areas | ||
| Network | |||
| Protocols | L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, SIP, QoS | ||
| Compatible Integration | ONVIF | ||
| Interface | |||
| Network | 1 RJ45 10M/100M Base-TX Ethernet | ||
| General | |||
| Power | 12 V DC, or PoE (IEEE802.3 af) | ||
| Power consumption: Max 6.4 W | |||
| Dimensions (L × W × H) | 157.3 × 62.4 ×63 mm (6.2″ × 2.5″ × 2.5″) | ||
| Weight | 0.45 kg (0.99 lb) | ||
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) | ||
| Ingress Protection | IP66 | ||
