| Model | NVR202-08E | NVR202-16E | NVR202-32E |
| Video and Audio | |||
| IP Video Input | 8-ch | 16-ch | 32-ch |
| Two-way audio Input | 1-ch, RCA | ||
| Network | |||
| Incoming bandwidth | 80Mbps | 160Mbps | 200Mbps |
| Outgoing bandwidth | 96Mbps | ||
| Remote connection | 128 | ||
| Video/Audio Output | |||
| HDMI/VGA Output | HDMI/VGA:
1920x1080p /60Hz, 1920x1080p /50Hz, 1600×1200 /60Hz, 1280×1024 /60Hz, 1280×720 /60Hz, 1024×768 /60Hz |
||
| Recording Resolution | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||
| Audio Output | 1-ch, RCA | ||
| Synchronous Playback | 8-ch | 16-ch | |
| Decoding | |||
| Compression | H.264 | ||
| Live view/Playback | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||
| Capability | 2 x 4MP@20, 4 x 1080p@30, 8 x 720p@25 | 4x 4MP@20, 6 x 1080p@25, 16 x 720p@25, 32 x D1 | |
| Hard Disk | |||
| SATA | 2 SATA interfaces | ||
| Capacity | up to 6TB for each disk | ||
| External Interface | |||
| Network Interface | 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface | ||
| USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 | ||
| General | |||
| Power Supply | 12V DC | ||
| Consumption ( without HDD ) | ≤ 8 W | ||
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) | ||
| Working Humidity | 10% ~ 90% | ||
| Dimensions | 44 × 360 × 254mm ( 1.7” × 14.2” × 10.0” ) | ||
| Weight ( without HDD ) | ≤ 1.42 Kg ( 3.13 lb ) | ||
