Açıklama
| Model | NVR204-16E | NVR204-32E |
| Video and Audio | ||
| IP Video Input | 16-ch | 32-ch |
| Two-way audio Input | 1-ch, RCA | |
| Network | ||
| Incoming bandwidth | 160Mbps | 200Mbps |
| Outgoing bandwidth | 96Mbps | |
| Remote connection | 128 | |
| Video/Audio Output | ||
| HDMI/VGA Output | HDMI/VGA:
1920x1080p /60Hz, 1920x1080p /50Hz, 1600×1200 /60Hz, 1280×1024 /60Hz, 1280×720 /60Hz, 1024×768 /60Hz |
|
| Recording Resolution | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
| Audio Output | 1-ch, RCA | |
| Synchronous Playback | 16-ch | |
| Decoding | ||
| Compression | H.264 | |
| Live view/Playback | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
| Capability | 4 x 4MP@20, 6 x 1080p@25, 16 x 720p@25, 32 x D1 | |
| Hard Disk | ||
| SATA | 4 SATA interfaces | |
| Capacity | up to 6TB for each disk | |
| External Interface | ||
| Network Interface | 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces | |
| Network Function | HTTP, TCP/IP, IPV4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Server, P2P | |
| Serial Interface | 1 x RS-485 | |
| USB Interface | Front panel: 1 x USB2.0
Rear panel: 1 x USB2.0, 1 x USB3.0 |
|
| Alarm In | 8-ch | |
| Alarm Out | 2-ch | |
| General | ||
| Power Supply | 12V DC | |
| Consumption ( without HDD ) | ≤ 8 W | |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) | |
| Working Humidity | 10% ~ 90% | |
| Dimensions | 44 × 440 × 341mm ( 1.7” × 17.3” × 13.4” ) | |
| Weight ( without HDD ) | ≤ 3.09 Kg ( 6.81 lb ) | |
