| Model |
SD65C82C-HN |
| Camera |
| Image Sensor |
1/3″ EXMOR CMOS |
| Effective Pixels |
1944 (H) x1092 (V) 2.0megapiksel |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
1/1~1/30000s |
| Min. Illumination |
Color: 0.05 Lux @F1.6 – B/W: 0.005 Luxx @F1.6 |
| S/N Ratio |
More than 50dB |
| Video Output |
BNC(1.0Vp-p/75Ω), PAL / NTSC |
| Camera Features |
| Day/Night |
Auto(ICR) / Color / B/W |
| Backlight Compensation |
BLC / HLC / DWDR |
| White Balance |
Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control |
Auto / Manual |
| Noise Reduction |
2D / 3D |
| Privacy Masking |
Up to 24 areas |
| Digital Zoom |
16x |
| Lens |
| Focal Length |
4.3mm~129mm(30x Optical zoom) |
|
|
| Max Aperture |
F1.6~F5 |
|
| Focus Control |
Auto / Manual |
| Angle of View |
H: 58.9°~2.1° |
|
| Close Focus Distance |
10mm ~ 1200mm |
|
| PTZ |
| Pan/Tilt Range |
Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~ 250°/s |
| Preset Speed |
Pan: 400°/s; Tilt: 300°/s |
| Preset |
80(DH-SD), 255(Pelco-P/D) |
| PTZ Mode |
5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup |
Human-oriented focal length/ speed adaptation |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
| Idle Motion |
Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period |
| Time Task |
Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time |
| Protocol |
DH-SD, Pelco-P/D (Auto recognition) |
| Video |
| Compression |
H.264 / MJPEG |
| Resolution |
1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) |
| Frame Rate |
Main Stream |
1080P/720P(1~25/30fps) 720P(1 ~ 25/30fps) |
|
| Sub Stream |
D1/CIF(1 ~ 25/30fps) |
| Bit Rate |
H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps |
| Audio |
| Compression |
G.711a / G.711u(32kbps) / PCM(128kbps) |
| Interface |
1/1 channel In/Out |
