| Model | SD65C82A-HN | |||
| Camera | ||||
| Image Sensor | 1/3″ EXMOR CMOS | |||
| Effective Pixels | 1944 (H) x1092 (V) 2.0megapiksel | |||
| Scanning System | Progressive | |||
| Electronic Shutter Speed | 1/1~1/30000s | |||
| Min. Illumination | Color: 0.05 Lux @F1.6 – B/W: 0.005 Luxx @F1.6 | |||
| S/N Ratio | More than 50dB | |||
| Video Output | BNC(1.0Vp-p/75Ω), PAL / NTSC | |||
| Camera Features | ||||
| Day/Night | Auto(ICR) / Color / B/W | |||
| Backlight Compensation | BLC / HLC / WDR | |||
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | |||
| Gain Control | Auto / Manual | |||
| Noise Reduction | 2D / 3D | |||
| Privacy Masking | Up to 24 areas | |||
| Digital Zoom | 16x | |||
| Lens | ||||
| Focal Length | 4.7mm~94mm(20x Optical zoom) | |||
| Max Aperture | F1.6~F3.5 | |||
| Focus Control | Auto / Manual | |||
| Angle of View | H: 55.4°~2.9° | |||
| Close Focus Distance | 10mm ~ 1000mm | |||
| PTZ | ||||
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° | |||
| Manual Control Speed | Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~ 250°/s | |||
| Preset Speed | Pan: 400°/s; Tilt: 300°/s | |||
| Preset | 80(DH-SD), 255(Pelco-P/D) | |||
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan | |||
| Speed Setup | Human-oriented focal length/ speed adaptation | |||
| Power up Action | Auto restore to previous PTZ and lens status after power failure | |||
| Idle Motion | Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period | |||
| Time Task | Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time | |||
| Protocol | DH-SD, Pelco-P/D (Auto recognition) | |||
| Video | ||||
| Compression | H.264 / MJPEG | |||
| Resolution | 1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) | |||
| Frame Rate | Main Stream | 1080P/720P(1~25/30fps) 720P(1 ~ 25/30fps) |
||
| Sub Stream | D1/CIF(1 ~ 25/30fps) | |||
| Bit Rate | H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps | |||
| Audio | ||||
| Compression | G.711a / G.711u(32kbps) / PCM(128kbps) | |||
| Interface | 1/1 channel In/Out | |||
