| Model | IPC568E-G |
| Camera | |
| Sensor | 1/1.7″ CMOS, progressive scan |
| Day & Night | Automatically removable IR-cut filter(ICR) |
| Shutter | Auto/Manual, 1/6~1/8000 s |
| Min. Illumination | Colour: 0.06 Lux (F1.2, AGC ON)
0 Lux with IR |
| S/N | >55dB |
| WDR | Digital |
| Lens Mount | CS |
| DC-Iris | DC 4V (4-Pin) |
| Motor Zoom/focus | DC 5V (4-Pin) |
| Video | |
| Max. Resolution | 4000 × 3000 |
| Video Compression | H.265, H.264, MJPEG |
| Frame Rate | 12 MP (4000×3000):Max.20 fps; 4K (3840×2160):Max.30 fps |
| 9:16 Corridor Mode | Supported |
| ROI | Supported |
| HLC | Supported |
| Defog | Optical Defog & Digital Defog |
| Video Streaming | Triple |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas |
| Audio | |
| Audio Compression | G.711 |
| Two-way Talking | Supported |
| Storage | |
| Edge Storage | Micro SD, up to 128 GB |
| Network | |
| Protocols | L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, SIP, 802.1x |
| Compatible Integration | ONVIF, API |
| Interface | |
| Audio I/O | 3.5 mm audio interface |
| 1 Input: impedance 35 kΩ; amplitude 2 V [p-p] | |
| 1 Output: impedance 600 Ω; amplitude 2 V [p-p] | |
| Alarm I/O | 2 / 1 |
| Serial Port | 1 RS485 (support Pelco-D/P) |
| Network | 100M/1000M Base-FX SFP + 100M/1000M Base-TX Ethernet |
| Video Output | 1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
| General | |
| Power | 24 V AC, 12 V DC, or PoE (IEEE802.3 af) |
| Power consumption: 6.5W (9.5W with ICR on) | |
| Dimensions (L x W x H) | 151.5 x 71 x 65 mm (6.0“ x 2.8“ x 2.6”) (excluding the lens) |
| Weight | 0.48 kg (1.1 lb) |
| Working Environment | –20°C ~ 60°C (-4°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
